Class 100-100000 Level Hospital Clean Engineering for Operation Room

The medical clean engineering system covers clean operating rooms, ICUs, disinfecting supply rooms, laboratories, clinical laboratories, vein deployment centers and other sites. Decoration materials, clean air-conditioners and medical devices that meet the cleanliness requirements must be adopted to ensure cleanliness, especially for clean operating rooms, ICUs, disinfecting supply rooms and other sites subject to cleanliness requirements of the hospital.

Level	Name of the operating room	Type of operation incisions	Applicable operating instructions
I	Special clean operating room	I	Joint replacement operation, organ transplantation operationand aseptic operation for cerebral surgery, cardiac surgery and gynecological surgery.
II	Standard clean operating room	I	Department of thoracic surgery, department of orthopedics and department of urology; Hepatobiliary and pancreatic surgery, Bone surgery and ovum extraction and Class A aseptic operation in general surgery
III	General clean operating room	I	General surgery (except Class A incision operation) and other operations like gynecological and obstetric department operations
IV	Quasi clean operating room	I	Anorectal surgery and contaminant operations

Name	Qty	Specification and parameter
Built-in device cabinet	1 set	Each room is provided with 1 set made of L304 stainless steel materials, 900×1700×350, opened by four doors, with the upper and lower layers provided with high strength glass trailers, on which sufficient surgical equipment can be placed. The cabinets are made of 1.2mm frosted stainless steel plates, and the colors of cabinet doors are similar or the same with the main colors of the operating room, with aluminum alloy or stainless steel used for edge wrapping around, and they can be locked.
Built-in anesthetic cabinet	1 set	Each room is provided one set, with other requirements the same as above.
Built-in drug cabinet	1 set	Each room is provided one set, with other requirements the same as above.
View boxes (Film Viewer)	1 set	Built-in; 100-class operating room is provided with six couplet view boxes, and other operating rooms are provided with quadruple view boxes. 4 pieces of flexible shifting masking can achieve film reading without glare; and the exterior panels are made of scratch resistant toughened glass, with interior layers made of advanced optical acrylic plates; and the panels are designed without screws, which are elegant and aesthetic, with the housing subject to powder spraying treatment capable of resisting corrosion by sterilizing agents.
Built-in writing table	1 set	Each operating room is provided with one, made of L304-1.2mmstainless steel material, with lighting and convenience in maintenance and replacement.
Heat insulation cabinet	/	Preferably 1 set
Multifunctional information control box	1 set	The operating room is provided with six control panels. The major functions include clock, double timer clock, control screen(common ceiling mounted lighting system switches and electric equipment control switches), telephone functions, air-conditioning system (temperature and humidity control), call and other control.
Infusion ducts	1 set	Each room is provided with 1 set, and each set contains 2 stainless steel rings.
Combined Power Socket box	3 groups	There are three 220V 15A power sockets for each group, with bottom boxes and covers; and 1 grounding terminal.
Combined power socket box	1 group	Each group is provided with one 3-phase 380V 20A power socket, two 220V 15A power sockets, with bottom boxes and covers; and 1 grounding terminal.
Air supply ceiling (laminar hoods)	1 set	1) The box is the double layer structure, with the inner layer made of stainless steel plates or attached with PVC film steel plates, and outer layer made of color steel plates, and with the interior filled with Level B1 XPS plates, and high strength aluminum alloy frames to ensure that the boxes have considerable ability to resist pressure, with heat insulation performance and resistance to corrosion; 2) High efficiency side cloth to ensure considerable static pressure volume; 3) Double-layer current equalizers are used to ensure uniform air supply; 4) The middle part is provided with medium-speed air flow compensation devices used to set off the impact of a rise in air flow out of heat from equipment and personnel on the Cleaning result.
Anchor bolts for shadowless lamps	/	1 set/room
Tower crane anchor bolts	/	1 set/room
