Home > Products > Relays And Timers > Digital Switch Timer Weekly Electric Outlet Timer

Digital Switch Timer Weekly Electric Outlet Timer

Basic Info

Model No.:  BSS2029

Product Description

Model NO.: BSS2029 Usage: Timer Switch, Multifunctional, Time Counter, Industrial, Electromagnetic Counter, Kitchen, Summation Meter, Universal Counter Theory: Digital Carry Base: Decimal Counter PLC Type: SP PLC Transport Package: Standard Export Packing Type: Timer Function: Addition Counter, Reversible Counter, Subtract Counter Carry Mode: Synchronous Counter Mechanism: Electronic Trademark: OMWO Origin: Zhejiang
Description : Standard Electronic & Mechanical Timer,IP20
Specification : 1)With children protector ;With indicator and with switch
2) 48 ON/PFF per day, single outlet
3)150V~, 15A, 60Hz,Maximum switching resistive 1875W load (e.g. incandescent lamp/bulbs, heating cables, etc.)or 500 W inductive load (e.g. devices with coils, such as transformers, ballasts, etc.)
4)Precision:+5 minutes ,RH: 0-95%,Working Temperature:-15-80
5)Used for In-house appliance controlling, Time-controlled switching off ,for example: TV, lighting, heating system ,cooling system, as well as sprinkler systems for terrariums, humidifiers, flow pumps for aquariums, ventilators, dosing and CO2 systems, manual switchover of operation modes Aautomatic, Permanent ON.
Material details : PC+COPPER
Product size (mm) : 75x84x121mm    1.0 lbs
Available colours : Any solid color
Packing: Double Blister + Inster card
Certification Marks : CE ,ROHS
MASTER CARTON INNER CARTON
Units per CARTON : 48 Units per INNER : 12
Net Weight (kgs) : 10 Net Weight (kgs) : 2
Gross Weight (kgs) : 14 Gross Weight (kgs) : 3
Unit Volume (M3): 0.081 Unit Volume (M3): 0.016
Dimensions (cms) : L x W x L x Wx H
62.0 49.0 26.0 47.0 30.0 11.5
CONTAINER LOADABILITY    Units/20' FCL : 17,328PCS      Units/40' FCL : 35,520PCS

With load indicator
With switch knob
With children protector
With grounded pin

Option        Min. setting time       Max. setting time    Program per day
Option A            15 minutes             24 hours             48 ON/OFF
Option B              2 hours                7 days              6 ON/OFF
Digital Switch Timer Weekly Electric Outlet Timer
Digital Switch Timer Weekly Electric Outlet Timer
Digital Switch Timer Weekly Electric Outlet Timer
Digital Switch Timer Weekly Electric Outlet Timer
Digital Switch Timer Weekly Electric Outlet Timer
Digital Switch Timer Weekly Electric Outlet Timer


Contact us if you need more details on Digital Timer. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Electric Outlet Timer、Timer Socket. If these products fail to match your need, please contact us and we would like to provide relevant information.
