Model No.: MWNES-35-48
1.High Efficiency and good price
2.Built-in EMI filter
3.100% full load burn-in test
4.Low output ripple and noise
5.Protection:Over load/Over voltage/Short circuit
|Rated output current||7A||3A||1.5A||0.8A|
|Output current range||0~7A||0-3A||0-1.5A||0-0.8A|
|Ripple and noise||80mVp-p||120mVp-p||120mVp-p||200mVp-p|
|INPUT||AC voltage range||85~132VAC/170~264VAC selected switch 47~63Hz|
|AC Inrush current||18A/115V 36A/230V|
|PROTECTION||Overload||105%~150% Type:pulsing hiccup shutdown Resete:auto recovery|
|SAFETY||Setup rise hold up time||200ms,100ms,30ms|
|Vibration||10~500Hz,2G 10min./1cycle,Period for 60min,EACH AXES|
|Withstand voltage||Input and output interval,1.5KVAC,Input and enclosure,1.5KVAC,Output and enclosure,0.5KVAC|
|Isolation resistance||Input and output interval,Input and enclosure,Output and enclosure,500VAC/100M Ohms|
|ENVIRONMENT||Temperature coeffi cient||±0.03%/°C (0~50°C )|
|Working temperature and humidity||-10°C~+60°C,20~90%RH|
|Store temperature and humidity||-20°C~+85°C,10~95%RH|
|OTHER||Overall dimension||130*98*38mm 45PCS/CARTON|
|CERTIFICATE||CE EMC Authenticate||EN55022:2010 EN61000-3-2:2006+AL:2009 EN61000-3-3:2008|
|EN55024:2010 EN55015:2006+AL2007+2009 EN61547:2009|
|CE LVD Authenticate||EN61347-1:2008T A1:2001 EN61347-2-13:2006|
|ROHS Authenticate||EPA3050B:1996 EN1122B:2001 EPA3052:1996 EPA3060A:1996|
|EPA7196A:1992 EPA3540C:1996 EPA8270D:2007 IEC62321:2008|
Contact us if you need more details on Switching Power Supply. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Switch Power Supply、LED Switch Power Supply. If these products fail to match your need, please contact us and we would like to provide relevant information.
