Home > Products > Single Output Switching Power Supply > Single Output Switch Mode Power Supply 35W 15V 2.4A

Single Output Switch Mode Power Supply 35W 15V 2.4A

Productivity:
50000/Month
Place of Origin:
Zhejiang
Supply Ability:
50000/Month
Certificate:
CE, UL, RoHS, ISO, CCC, CB, CSA
  • Mr. Catherine Zhou

Basic Info

Model No.:  MWNES-35-15

Product Description

Model NO.: MWNES-35-15 Warranty: >2 Years Input Voltage: 15V Starting Mode: Self-excited Switching Power Supply Power Supplying System: Terminal Power Distribution Equipment Modulation System: PFAW Brand: Omwo Specification: 159*98*38mm HS Code: 8504401990 Output Type: Single Output Power: 1 - 50W Connection Mode: Series Switching Power Supply Voltage Regulating Mode: Frequency Modulation Type Energy Transmission: Two-way Transmission Certification: CE, UL, RoHS, ISO, CCC, CB, CSA Trademark: OMWO Origin: Zhejiang MWNES-35-15 35W 15V 2.4A top grade classical variable dc power supply   Product Description Where is our power supply use?                                                                               1.Power tools series:Electric saw,Drilling machine,Ginder,Sand blast Machine,Puching Machine,Weeding Machine,Air Compressor etc. 2.Office series:Computer,Printer,LCD Monitor,Scanning Machine etc. 3.Household Appliance series:Dust Collector,Fan Lamp or LED,Sewing Machine etc. 4.Kitchen Appliance series:Microwave Oven,Fridge,Freezr,Coffemarker etc. 5.Industrial Equipment series:Shipping,Vehicle,Metalhalide lamp,Solor system,Wind power generation etc. 6.Electric filed series:TV,VCRS,Radio ect.








1.Low price and high reliability
2.105 output capacitor
3.AC input power suitable for the world
4.High efficiency and low operation temperature
5.Soft-start current can reduce the AC input impact effectively
6.With short-circuit and overload protection

7.Compact size, light weight
8.100% full-load burning test
9.Installed with EMI filter, minimum wave


Model
Specification
S-35-5 S-35-12 S-35-15 S-35-24
DC output voltage 5V 12V 15V 24V
Output voltage error(Note2) ±2% ±1% ±1% ±1%
Rated output current 7A 3A 2.4A 1.5A
Output current range 0-7A 0-3A 0-2.4A 0-1.5A
Wave and noise(Note3) 75mVp-p 100mVp-p 100mVp-p 100mVp-p
Inlet stability(Note4) ±0.5% ±0.5% ±0.5% ±0.5%
Load stability(Note5) ±1% ±0.5% ±0.5% ±0.5%
DC output power 35W 36W 36W 36W
Efficiency 70% 76% 78% 78%
Adjustable range for DC voltage ±10,-5% ±10% ±10% ±10%
AC input voltage range 85132VAC/170264VACselected by switch
Input current 0.85A/115V 0.45A/230V
AC impulse current Cold-start current 18A/115V 36A/230V
Leakage current <0.5mA/240VAC
Overload protection 105%150% Type: current limiting;  Reset: auto recovery
Over-voltage protection
High-temperature protection
Temperature coefficient ±0.03%(050)
Setup rise hold up time 200ms,100ms,30ms
Vibration 10500Hz,2G 10min./1cycle,Period for 60min,Each axes
Withstand voltage Input and output intermal:1.5KVAC,Input and enclosute:1.5KVAC,Output and enclosure:0.5KVAC
Isolation resistance Input and output interval,Input and enclosure,Output and enclosure0500VAC/100M Ohms
Working temperature and humidity -10+60,20%90%RH
Store temperature and humidity -20+85,10%95RH
Overall dimension 129*98*38mm
Weight 0.4Kgs
Safety standards Meet UL 1012 requirement(Not apply for the mark)
EMC standards Meet FCC Part 15J Conduction Class B
Note:
1.The testing condition for the parameter above is:230VAC input, rated load,25 70%Rh,Humidity
2.Error,include the setting error, line stability and load stability.(Note:5)
3.Wave test:adoptingA12double wire for 20MHz,and 0.1uF&uF capacitor short-circuit for interrupting
4.Inlet voltage stability test: when is over load, the lowest voltage of inlet is representative to the highest voltage.
5.Load stability test: The load is from 0% to 100%,Others 60%.
6.C2311must be knocked down.
  Single Output Switch Mode Power Supply 35W 15V 2.4ASingle Output Switch Mode Power Supply 35W 15V 2.4ASingle Output Switch Mode Power Supply 35W 15V 2.4ASingle Output Switch Mode Power Supply 35W 15V 2.4ASingle Output Switch Mode Power Supply 35W 15V 2.4A   Technique parameter   Features of variable dc power supply AC input range selectable by switch  Protections: Short circuit / Overload / Over voltage   Cooling by free air convection   LED indicator for power on   100% full load burn-in test  High efficiency, long life and high reliability  2 years warranty
