100W Single Output Nes-100-9 Switching Power Supply 9V

Basic Info

Model No.:  MWNES-100-9

Product Description

Model NO.: MWNES-100-9 Warranty: >2 Years Input Voltage: 24V Starting Mode: Self-excited Switching Power Supply Power Supplying System: Terminal Power Distribution Equipment Modulation System: PFAW Brand: Omwo Specification: 159*98*38mm HS Code: 8504401990 Output Type: Single Output Power: 1 - 50W Connection Mode: Series Switching Power Supply Voltage Regulating Mode: Frequency Modulation Type Energy Transmission: Two-way Transmission Certification: CE, UL, RoHS, ISO, CCC, CB, CSA Trademark: OMWO Origin: Zhejiang MODEL         NES-100-5    NES-100-7.5    NES-100-9    NES-100-12    NES-100-15   NES-100-24   NES-100-48 DC VOLTAGE         5V               7.5V                  9V               12V                  15V               24V                48V CURRENT RANGE 0~ 20A      0~13.6A          0~11.2A        0~8.5A             0~7A            0~4.5A          0~2.3A RATED CURRENT   20A            13.6A               11.2A            8.5A                  7A                4.5A                2.3A RATED POWER   100W            102W              100.8W        102W               105W            108W           110.4W RIPPLE & NOISE 80mVp-p   120mVp-p       120mVp-p      120mVp-p     120mVp-p     120mVp-p        150mVp-p VOLTAGE ADJ. RANGE  4.75 ~ 5.5V    7.13 ~ 8.3V   8.55 ~ 9.9V   11.4 ~ 13.2V  14.25 ~ 16.5V 22.8 ~ 26.4V 45.6 ~ 52.8V VOLTAGE TOLERANCE 2.0%     1.0%             1.0%            1.0%                 1.0%              1.0%             1.0% LINE REGULATION  0.5%         0.5%              0.5%            0.5%                  0.5%             0.5%             0.5% LOAD REGULATION 0.5%         0.5%              0.5%             0.5%                0.5%              0.5%             0.5% SETUP, RISE TIME 500ms, 20ms/230VAC 500ms, 20ms/115VAC at full load HOLD UP TIME 30ms/230VAC 25ms/115VAC at full load  INPUT VOLTAGE RANGE 85 ~ 132VAC / 176 ~ 264VAC selected by switch 248 ~ 373VDC FREQUENCY RANGE 47 ~ 63Hz EFFICIENCY (Typ.) 80% 81% 81% 83% 84% 86% 86% AC CURRENT (Typ.) 2A/115VAC 1.2A/230VAC INRUSH, CURRENT (Typ.) COLD START 36A LEAKAGE CURRENT PROTECTION OVER LOAD 110 ~ 150% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed OVER VOLTAGE 5.75 ~ 6.75V 8.6 ~ 10.1V 10.4 ~ 12.2V 13.8 ~ 16.2V 17.25 ~ 20.25V 27.6 ~ 32.4V 55.2 ~ 64.8V Protection type : Hiccup mode, recovers automatically after fault condition is removed ENVIRONMENT WORKING TEMP. -20 ~ +60oC (Refer to output load derating curve) WORKING HUMIDITY 20 ~ 90% RH non-condensing STORAGE TEMP., HUMIDITY -40 ~ +85oC , 10 ~ 95% RH TEMP. COEFFICIENT 0.03%/oC (0 ~ 45oC ) VIBRATION 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes SAFETY SAFETY STANDARDS UL60950-1, CB(IEC60950-1) approved WITHSTAND VOLTAGE I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC ISOLATION RESISTANCE I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC STANDARD EMI CONDUCTION & RADIATION Compliance to EN55022 (CISPR22) Class B HARMONIC CURRENT Compliance to EN61000-3-2,-3 EMS IMMUNITY Compliance to EN61000-4-2, 3, 4, 5, 6, 8,11, ENV50204, EN55024, EN61000-6-1, light industry level, criteria A Others Dimension 159*98*38mm (L*W*H) Weight 0.57Kg Packing 30pcs/17.9Kg.According to your order,we can provide different cartons for you. NOTE: 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25oCof ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation. 4. Line regulation is measured from low line to high line at rated load. 5. Load regulation is measured from 0% to 100% rated load. 6. The power supply is considered a component which will be installed into a final
100W Single Output Nes-100-9 Switching Power Supply 9V
100W Single Output Nes-100-9 Switching Power Supply 9V100W Single Output Nes-100-9 Switching Power Supply 9V100W Single Output Nes-100-9 Switching Power Supply 9V100W Single Output Nes-100-9 Switching Power Supply 9V100W Single Output Nes-100-9 Switching Power Supply 9V

Contact us if you need more details on Switching Power Supply. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Switch Power Supply、LED Switch Power Supply. If these products fail to match your need, please contact us and we would like to provide relevant information.
