Home > Products > Single Output Switching Power Supply > Hot Sell Nes-100 SMPS 100W Ad/DC LED Driver Power Supply

Hot Sell Nes-100 SMPS 100W Ad/DC LED Driver Power Supply

Basic Info

Model No.:  NES-100

Product Description

Model NO.: NES-100 Warranty: >2 Years Input Voltage: 24V Starting Mode: Self-excited Switching Power Supply Power Supplying System: Terminal Power Distribution Equipment Modulation System: PFAW Brand: Omwo Trademark: OMWO Origin: Zhejiang Output Type: Single Output Power: 1 - 50W Connection Mode: Series Switching Power Supply Voltage Regulating Mode: Frequency Modulation Type Energy Transmission: Two-way Transmission Certification: CE, UL, RoHS, ISO, CCC, CB, CSA Size: 159*98*38mm Specification: 159*98*38mm HS Code: 8504401990 switching supply
Rated power: 100W
Output voltage: DC 15V
Ripple & Noise (max.): 100mVp-p
Over load protection: 110~115% rated output power
Over voltage protection:16.5~20.25V

Over temperature protection: 100°C±5°
Business type: Manufacturer/Factory

 Product Description
 100w 8.3 ampere 12v power switching supply  features:

v  High efficiency up to 82%
v  Protection: Short circuit/Overload /Over Voltage/Over Temperature
v       Suitable for dry/damp/wet locations
v  Bult-in constant current limiting circuit
 100w 8.3 ampere 12v power switching supply  details:
 100w Series, include output 3.3v, 5v, 12v ,15v,24V and 36v.

Model   HB-100W-3.3V HB-100W-5V HB-100W-12V HB-100W-15V HB-100W-24V HB-100W-36V
Output DC Voltage 3.3V 5V 12V 15V 24V 36V
Rated Current 30A 20A 8A 6.5A 4A 2.5A
Current Range 0~30A 0~20A 0~8A 0~6.5A 0~4A 0~2.5A
Rated Power 99W 100W 96W 97.5W 96W 90W
Ripple & Noise (max.) 100mVp-p 100mVp-p 100mVp-p 150mVp-p 150mVp-p 150mVp-p
Voltage Adj. Range 3.14~3.63V 4.75~5.5V 11.4~13.2V 14.3~16.5V 22.8~26.4V 34.2~39.6V
Voltage Tolerance ±2.0% ±2.0% ±2.0% ±2.0% ±1.0% ±1.0%
Line Regulation ±1.0% ±1.0% ±1.0% ±1.0% ±0.5% ±0.5%
Load Regulation ±5.0% ±5.0% ±5.0% ±5.0% ±5.0% ±5.0%
Setup,Rise time 600ms,30ms at full load
Hold Up Time(Typ.) 13ms at full load
Input Voltage Range                   90~132VAC/180~264VAC
Frequency Range 47~63HZ
Efficiency(Typ.) 81% 82% 82% 85% 87% 90%
AC Current (Typ.) 5A/115VAC         3A/230VAC
Inrush Current (Typ.) 20A/115VAC         40A/230VAC
Leakage Current <2mA / 240VAC
Protection Over Load 110~115% rated output power
Protection type: Shut down O/P,re-power on to recover
Over Voltage 3.63~4.46V 5.5~6.75V 13.2~16.2V 16.5~20.25V 26.4~32.4 39.6~48.6V
Protection type: Shut down O/P,re-power on to recover
Over Temperature 100°C±5°C(3.3V~12V); 105°C±5°C(15V~36V); TSW1 detect on main power transformer for Others
Protection type: Shut down O/P,recovers automatically after temperature goes down
Environment Working Temperature  -20~+60°C
Working Humidity 20~90% RH  Non-condensing
Storage temp.& humidity -20~+85°C, 10~95%RH
Temp. coefficient ±0.03%/°C (0~50°C)
Vibration 10 ~ 500Hz, 3G 10min./1 cycle,60min.each along X,Y,Z axes
Safety & EMC Safety Standards UL60950-1 approved
Withstand Voltage I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
Isolation Resistance I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25°C/ 70% RH
Others MTBF 10000hrs     MIL-HDBK-217F (25°C)
Dimension 160*98*38mm (L*W*H)
Packing 0.36Kg; 48pcs/19.5Kg/1.85CUFT
Note 1. All parameters NOT specially mentioned are measured at 220VAC input, rated load and 25°C of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 10uf parallel capacitor.
3. Tolerance: includes set up tolerance, line regulation and load regulation.
4. Derating may be needed under low input voltages.
