Home > Products > Single Output Switching Power Supply > Universal Regulated Switching Power Supply Nes-35-48

Universal Regulated Switching Power Supply Nes-35-48

Productivity:
50000/Month
Place of Origin:
Zhejiang
Supply Ability:
50000/Month
Certificate:
CE, UL, RoHS, ISO, CCC, CB, CSA
  • Mr. Catherine Zhou

Basic Info

Model No.:  MWNES-35-48

Product Description

Model NO.: MWNES-35-48 Warranty: >2 Years Input Voltage: 15V Starting Mode: Self-excited Switching Power Supply Power Supplying System: Terminal Power Distribution Equipment Modulation System: PFAW Brand: Omwo Specification: 159*98*38mm HS Code: 8504401990 Output Type: Single Output Power: 1 - 50W Connection Mode: Series Switching Power Supply Voltage Regulating Mode: Frequency Modulation Type Energy Transmission: Two-way Transmission Certification: CE, UL, RoHS, ISO, CCC, CB, CSA Trademark: OMWO Origin: Zhejiang Specifications universal regulated switching power supply
1.CE CCC Approval
2.ISO9001 standard company
3.Historical manufacturing of SMPS
universal regulated switching power supply   Product Description
Model                         NES-35-5         NES-35-12           NES-35-15          NES-35-24        NES-35-48 DC Voltage                       5V                   12V                      15V                     24V                   48V Rated Current                  7A                    3A                       2.4A                    1.5A                  0.8A Current Range               0 ~ 7A             0 ~ 3A                 0 ~ 2.4A             0 ~ 1.5A            0 ~ 0.8A Rated Power                  35W                  36W                     36W                    36W                 38.4W


Universal Regulated Switching Power Supply Nes-35-48Universal Regulated Switching Power Supply Nes-35-48Universal Regulated Switching Power Supply Nes-35-48Universal Regulated Switching Power Supply Nes-35-48Universal Regulated Switching Power Supply Nes-35-48Universal Regulated Switching Power Supply Nes-35-48 Ripple & Noise            80mVp-p           120mVp-p             150mVp-p          200mVp-p          240mVp-p Voltage Adj. Range    4.75 ~ 5.5V      10.8 ~ 13.2V        13.5 ~ 16.5V       21.6 ~ 26.4V      43.2 ~ 52.8V Voltage Tolerance          ±2.0%             ±1.0%                  ±1.0%                 ±1.0%              ±1.0% Line Regulation              ±0.5%              ±0.5%                 ±0.5%                 ±0.5%              ±0.5% Load Regulation             ±0.5%              ±0.5%                 ±0.5%                 ±0.5%              ±0.5% Setup, Rise Time        500ms, 30ms/230VAC 1200ms, 30ms/115VAC at full load Hold Up Time            50ms/230VAC 10ms/115VAC at full load   INPUT Voltage Range 85 ~ 264VAC 120 ~ 370VDC Frequency Range 47 ~ 63Hz Efficiency 78% 81% 83% 85% 86% AC Current 0.75A/115VAC 0.5 A/230VAC Inrush Current Cold Start 45A Leakage Current
