Nes-150 5V 150W 110V/220V Wide Voltage AC/DC Switching Power Supply Driver

Basic Info

Model No.:  MWNES-150-2

Product Description

Model NO.: MWNES-150-2 Warranty: >2 Years Input Voltage: 24V Starting Mode: Self-excited Switching Power Supply Power Supplying System: Terminal Power Distribution Equipment Modulation System: PFAW Brand: Omwo Specification: 159*98*38mm HS Code: 8504401990 Output Type: Single Output Power: 1 - 50W Connection Mode: Series Switching Power Supply Voltage Regulating Mode: Frequency Modulation Type Energy Transmission: Two-way Transmission Certification: CE, UL, RoHS, ISO, CCC, CB, CSA Trademark: OMWO Origin: Zhejiang NES-150 5V 150W 110V/220V wide voltage AC/DC Switching Power Supply driver for CCTV system LED stripe 3D printer with CE ROHS SMPS
Features
1.High Efficiency and good price
2.Built-in EMI filter
3.100% full load burn-in test
4.Low output ripple and noise
5.Protection:Over load/Over voltage/Short circuit
6.LIFETIME WARRANTY!

Specifications
MODEL NES-150-5 NES-150-12 NES-150-24 NES-150-36 NES-150-48
OUTPUT DC VOLTAGE  5V 12V 24V 36V 48V
RATED CURRENT 26A 12.5A 6.5A 4.2A 3.3A
CURRENT RANGE 0 ~26A 0 ~ 12.5A 0 ~ 6.5A 0 ~ 4.2A 0~ 3.3A
RATED POWER 130W 150W 156W 151.2W 158.4W
RIPPLE & NOISE (max.) 80mVp-p 120mVp-p 120mVp-p 120mVp-p 200mVp-p
VOLTAGE ADJ. RANGE 4.75~5.5V 11.4~13.5V 22.8~27.6V 32.4~39.6V 45.6~52.8V
VOLTAGE TOLERANCE  ±2.0% ±1.0% ±1.0% ±1.0% ±1.0%
LINE REGULATION ±0.5% ±0.5% ±0.5% ±0.5% ±0.5%
LOAD REGULATION ±0.5% ±0.5% ±0.5% ±0.5% ±0.5%
SETUP, RISE TIME 800ms,30ms/230VAC 1200ms,30ms/115VAC  at full load
HOLD TIME 24ms/230VAC  10ms/115VAC at full load
INPUT VOLTAGE RANGE 90~132VAC/180~264VAC selected by switch    254~373VDC
FREQUENCY RANGE 47 ~ 63Hz
EFFICIENCY (Typ.) 78% 83% 86% 86% 86%
AC CURRENT 3A/115VAC   2A/230VAC
INRUSH CURRENT (max.) Cold Start 45A/230VAC
LEAKAGE CURRENT <2mA/240VAC
PROTECTION OVERLOAD 110~150% rated output power
Protection type : Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE 5.75~6.75V 13.8~16.2V 27.6~32.4V 41.4~48.6V 55.2~64.8V
Protection type :Shut off
ENVIRONMENT WORKING TEMP. -20 ~ +60°C
WORKING HUMIDITY 20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY -40 ~ +85°C, 10 ~ 95% RH
TEMP. COEFFICIENT ±0.02%/ (0 ~ 40°C)
VIBRATION 10 ~ 500Hz, 2G 10min./1cycle, 60min
SAFETY & EMC  SAFETY STANDARDS Desgin refer to UL1012,EN60950-1,EN61347-1,EN-61347-2 approved
WITHSTAND VOLTAGE I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
ISOLATION RESISTANCE I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
EMC EMISSION & IMMUNITY EN55015,EN55022,EN55024,EN61000-2,EN61000-3,EN61547 approved
Others MTBF ≥400K hrs min
DIMENSION 199×98×38mm (L*W*H)  0.7kg
