Home > Products > Single Output Switching Power Supply > 15W 5/12/24/48V Nes Series Efficient Single Switching Power Switching Power Supply

15W 5/12/24/48V Nes Series Efficient Single Switching Power Switching Power Supply

Productivity:
50000/Month
Place of Origin:
Zhejiang
Supply Ability:
50000/Month
Certificate:
CE, UL, RoHS, ISO, CCC, CB, CSA
  • Mr. Catherine Zhou

Basic Info

Model No.:  MWNES-100-1

Product Description

Model NO.: MWNES-100-1 Warranty: >2 Years Input Voltage: 15V Starting Mode: Self-excited Switching Power Supply Power Supplying System: Terminal Power Distribution Equipment Modulation System: PFAW Brand: Omwo Specification: 159*98*38mm HS Code: 8504401990 Output Type: Single Output Power: 1 - 50W Connection Mode: Series Switching Power Supply Voltage Regulating Mode: Frequency Modulation Type Energy Transmission: Two-way Transmission Certification: CE, UL, RoHS, ISO, CCC, CB, CSA Trademark: OMWO Origin: Zhejiang Specifications:
1.CE ROHS approved.
2.2 years warranty
3.79% efficiency
4.100-240VAC 0.5A 50/60Hz input
Notice:
a.We do have enough ability to produce your customized order
b.Samples are available
c.High quality and competive price .
d. 2 years warrenty ,buy with confidence
Features:
1. AC input range selectable by switch
2. Protections: Short circuit / Overload / Over voltage / Over temperature
3. 100% full load burn-in test
4. Low cost, high reliability
5. 24 months warranty
Data sheet :
we can stick customers' label as long as you can purchase enough quantity in a time.

MODEL NES-15-5 NES-15-12 NES-15-15 NES-15-24 NES-15-48
OUTPUT DC VOLTAGE 5V 12V 15 24V 48
RATED CURRENT 3A 1.3A 1 0.7 0.35
CURRENT RANGE 0 ~ 3A 0 ~ 1.3A 0 ~ 1A 0 ~ 0.7A 0 ~ 0.35A
RATED POWER 15W 15.6W 15W 16.8W 16.8W
RIPPLE & NOISE (max.) 150mVp-p 150mVp-p 150mVp-p 150mVp-p 200mVp-p
VOLTAGE ADJ. RANGE 4.75 ~ 5.5V 10.8 ~ 13.2V 13.5~16.5V 21.6 ~ 26.4V 43.2~52.8
VOLTAGE TOLERANCE ±2.0% ±1.0% ±1.0% ±1.0% ±1.0%
LINE REGULATION ±1.0% ±0.5% ±0.5% ±0.5% ±0.5%
LOAD REGULATION ±1.0% ±0.5% ±0.5% ±0.5% ±0.5%
SETUP, RISE TIME 1000ms,30ms at full load
HOLD TIME 100ms/230VAC  20ms/115VAC at full load
INPUT VOLTAGE RANGE 85~264VAC or120~370VDC
FREQUENCY RANGE 47 ~ 63Hz
EFFICIENCY (Typ.) 80% 82% 83% 85% 83%
AC CURRENT 0.35A/115VAC   0.25A/230VAC
INRUSH CURRENT (max.) COLD START 45A
LEAKAGE CURRENT <3mA/240VAC
PROTECTION OVERLOAD Above 105% rated output power
Protection type : Constant current limiting,
recovers automatically after fault condition is reoved
OVER VOLTAGE 5.8~6.8V 14~16V 17~20V 28~32V 55~64V
Protection type :Shut off
ENVIRONMENT WORKING TEMP. -20 ~ +60°C
WORKING HUMIDITY 20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY -30 ~ +85°C, 10 ~ 95% RH
TEMP. COEFFICIENT ±0.02%/ (0 ~ 40°C)
VIBRATION 10 ~ 500Hz, 2G 10min./1cycle, 60min
SAFETY & EMC SAFETY STANDARDS Desgin refer to UL1012,EN60950-1,EN61347-1,EN-61347-2 approved
WITHSTAND VOLTAGE I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
ISOLATION RESISTANCE I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
EMC EMISSION & IMMUNITY EN55015,EN55022,EN55024,EN61000-2,EN61000-3,EN61547 approved
Others MTBF 500K hrs min
DIMENSION 78×51×28mm (L*W*H)
WEIGHT 0.18KG

15W 5/12/24/48V Nes Series Efficient Single Switching Power Switching Power Supply
15W 5/12/24/48V Nes Series Efficient Single Switching Power Switching Power Supply15W 5/12/24/48V Nes Series Efficient Single Switching Power Switching Power Supply15W 5/12/24/48V Nes Series Efficient Single Switching Power Switching Power Supply15W 5/12/24/48V Nes Series Efficient Single Switching Power Switching Power Supply15W 5/12/24/48V Nes Series Efficient Single Switching Power Switching Power Supply
