S-35-24 Single Output Swtiching Power Supply

Place of Origin:
Supply Ability:
  • Mr. Catherine Zhou

Basic Info

Model No.:  S-35-24

Product Description

Model NO.: S-35-24 Warranty: >2 Years Input Voltage: 15V Starting Mode: Self-excited Switching Power Supply Power Supplying System: Terminal Power Distribution Equipment Modulation System: PFAW Brand: Omwo Specification: 159*98*38mm HS Code: 8504401990 Output Type: Single Output Power: 1 - 50W Connection Mode: Series Switching Power Supply Voltage Regulating Mode: Frequency Modulation Type Energy Transmission: Two-way Transmission Certification: CE, UL, RoHS, ISO, CCC, CB, CSA Trademark: OMWO Origin: Zhejiang China enclosed switching power supply manufacturers, built-in type chassis, metal shell, switch power supply can be used for room temperature environment. Universal ac input voltage range,have complete protection function, 100% full load aging test. Security monitoring, display, light box, suitable for indoor use.
S-35W series compact single switching power supply feature:
· Universal AC input range
· Small volume,low weight,high efficiency
· Protections: short circuit/over load
· Cooling by free air convection
· LED indicator for power on
· 100% full load burn-in test
Model S-35-5 S-35-12 S-35-15 S-35-24
DC voltage 5V 12V 15V 24V
Voltage tolerance ±2% ±1% ±1% ±1%
Rated current 7A 3A 2.4A 1.5A
Current range 0~7A 0~3A 0~2.4A 0~1.5A
Rated power 25W 36W 36W 36W
Ripple & noise 75mvp-p 100mvp-p 100mvp-p 100mvp-p
DC voltage adjustable range ±10% ±10% ±10% ±10%
Voltage range 80~264VAC,  120~370VDC
Frequency 47~63HZ
AC current 0.45A/230VAC
Efficiency 76% 78% 78% 80%
Inrush current Cold start current  30A/230VAC
Leakage current <1mA/240VAC
Over load
105 ~ 135% rated output power
Protection type: Hiccup mode, auto-recovery after fault condition is removed.
Over voltage
115 ~ 135% rated output power
Protection type: Hiccup mode, auto-recovery after fault condition is removed.
Working temp,humidity -10°C~+60°C, 20%~90%RH
Storage temp,humidity -20°C~+85°C, 10%~95%RH non-condensing
Withstand vibration 10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes
Withstand voltage I/P-O/P:1.5KVAC, I/P-FG:1.5KVAC, O/P-FG:0.5KVAC
Isolation resistance I/P-O/P, I/P-FG, O/P-FG: 100M ohms/500VDC
Fit standard
Safety standard Compliance to UL1012
EMC standard Compliance to EN55022,CLASS A
Dimension 84*58*38mm(L*W*H)
Weight/packing 0.15kg/80pcs/13kg/0.024m3/0.87CUFT
1 All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature.
2 Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3 Tolerance: includes set up tolerance, line regulation and load regulation.
S-35-24 Single Output Swtiching Power SupplyS-35-24 Single Output Swtiching Power SupplyS-35-24 Single Output Swtiching Power SupplyS-35-24 Single Output Swtiching Power Supply
