Home > Products > Single Output Switching Power Supply > 48V 2AMP AC DC S-100-5 12 24 48V Switching Power Supply

48V 2AMP AC DC S-100-5 12 24 48V Switching Power Supply

Basic Info

Model No.:  S-100-2

Product Description

Model NO.: S-100-2 Warranty: >2 Years Input Voltage: 24V Starting Mode: Self-excited Switching Power Supply Power Supplying System: Terminal Power Distribution Equipment Modulation System: PFAW Brand: Omwo Trademark: OMWO Origin: Zhejiang Output Type: Single Output Power: 1 - 50W Connection Mode: Series Switching Power Supply Voltage Regulating Mode: Frequency Modulation Type Energy Transmission: Two-way Transmission Certification: CE, UL, RoHS, ISO, CCC, CB, CSA Size: 159*98*38mm Specification: 159*98*38mm HS Code: 8504401990 12/24/48V 75W Single output High efficiency power supply Switching Power Supply
Product Description
Specifications:
1.CE RoHS approved
2.2 years warranty
3.high quality
4.79% efficiency
Notice:
a.We do have enough ability to produce your customized order
b.Samples are available
c.High quality and competive price .
d 2 years warrenty ,buy with confidence


General Specification :
Model S-75-12 S-75-15 S-75-24 S-75-48
DC output voltage 12V 15V 24V 48V
Rated output current 6A 5.0A 3A 1.5A
Output current range 0-6A 0-5A 0-3A 0-1.5A
Wave and noise 75mVp-p 100mVp-p 100mVp-p 100mVp-p
Inlet stability ±0.5% ±0.5% ±0.5% ±0.5%
Load stability ±0.5% ±0.5% ±0.5% ±0.5%
Efficiency 78% 79% 82% 83%
Adjustable range for DC voltage ±10% ±10% ±10% ±10%
AC input voltage range: 85~132VAC/170~264VAC selected by switch 47~63Hz;240~370VDC
AC inrush current: Cold-start current 15A/115V 30A/230V
Overload protection: 105%~150% Type:plusing hiccup shutdown Reset:auto recovery
Setup rise hold-up time: 200ms,50ms,20ms
Withstand voltage:Input and output internal: 1.5KvAC,Output and enclosure:0.5KvAC
Isolation resistance: Input and output internal,input and enclosure,output and enclosure:500VDC/100MΩ
Working temperature 0~50°C
Safety standards: GB4943 UL60950 EN60950
EMC standards: EN55022 GB9254,class A
Overall dimension: 159*97*38mm
Weight: 0.56Kgs

48V 2AMP AC DC S-100-5 12 24 48V Switching Power Supply48V 2AMP AC DC S-100-5 12 24 48V Switching Power Supply48V 2AMP AC DC S-100-5 12 24 48V Switching Power Supply48V 2AMP AC DC S-100-5 12 24 48V Switching Power Supply48V 2AMP AC DC S-100-5 12 24 48V Switching Power Supply11

Contact us if you need more details on Switching Power Supply. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Switch Power Supply、LED Switch Power Supply. If these products fail to match your need, please contact us and we would like to provide relevant information.

Product Categories : Single Output Switching Power Supply
